Airborne Radar EW Equipment

The airborne radar reconnaissance equipment is employed for the detection and positioning of enemy radars. It can obtain intelligence about enemy radars (in time domain, spatial domain and frequency domain), providing effective support for subsequent electromagnetic jamming and fire strikes.

ALZC/J-A-01

•Frequency Range: 2~18GHz (Customizable);
•Instantaneous Bandwidth: ≥ 1 GHz;
•Receiver Sensitivity:
•Better than -80dBm, PW ≥ 1μs;
•Better than -75dBm, 0.1 < PW < 1μs;
•Azimuth Area (Customizable):
•Horizontal: ≥ 270°;
•Elevation: ≥ 60°;
•Effective Range:≥350km (Typical Frequency @12GHz)
•Direction Finding Accuracy: 2° (R.M.S);
•Power Consumption: ≤ 120 W (powered by platform).

ALZC/J-A-03

•Frequency Range: 0.38~2GHz (Customizable);
•Instantaneous Bandwidth: ≥ 1 GHz;
•Receiver Sensitivity:
•Better than -75dBm, PW ≥ 1μs;
•Better than -70dBm, 0.1 < PW < 1μs;
•Azimuth Area(Customizable):
•Horizontal: -45°~+45°; Elevation: 0°~+30°;
•Direction Finding Accuracy: 5° (R.M.S);
•Effective range:≥500km (Typical Frequency @2GHz)
•Power Consumption: ≤ 120 W (powered by the platform).

Airborne Radar EW Equipment

The Airborne radar ECM equipment is used for covering the penetration and attacking mission of our aircraft units. It can be employed in the combat profile such as close support jamming in the defense area, escort flight jamming, distributed cluster jamming, etc., which can effectively interfere with enemy ground search and warning radars, ground air defense guidance radars and airborne fire control radars.

ALGRJ-2/18GHz-MINI

• Frequency Range: 2～18GHz;

• Instantaneous Operating Bandwidth: ≥1GHz;

• Receiving System Sensitivity: ≤-65dBm;

• Effective Radiated Power: ≥20W (customizable);

• Beam Coverage: Horizontal 50°, Elevation 30°;

• Jamming Mode: Noise jamming, Deception jamming, and Combined jamming;

• Communication Method: Communication via aircraft link, RS 422 interface;

• Power Consumption: ≤150W.
